Supplier for KaramA matching set of lifeline posts for trapezoidal metal roofs: an extremity post for the ends of the line (SA38A(E)N), an intermediate post (SA38A(I)N) and a 90 degree corner post (SA38A(C)(90)N), each designed for 4 users. In a fall the post deploys to absorb energy and leaves the roof panel intact.
Standards and approvals: EN795:2012 Type A, TS16415:2013 Type A, CE, EN795:2012 Type C, TS16415:2013 Type C
| Specification | SA38A(E)N | SA38A(I)N | SA38A(C)(90)N |
|---|---|---|---|
| Material | (Shock absorber assembly)- Stainless Steel, (Base plate)- Aluminium Alloy | (Shock absorber assembly)- Stainless Steel, (Base plate)- Aluminium Alloy | Material- (Shock absorber assembly)- Stainless Steel, (Base plate)- Aluminium Alloy |
| Installed on | Standing Seam | Standing Seam | Standing Seam |
| Finish | Electropolished / ED Coated | Electropolished / ED Coated | Electropolished / ED Coated |
| Weight | 3.74 kg ± 0.05 kg | 3.77 kg ± 0.05 kg | 4.37 kg ± 0.05 kg |
| Minimum Breaking Strength | 15kN | 15kN | 15kN |
| Conforms to | EN795:2012 Type A TS16415:2013 Type A | EN795:2012 Type C TS16415:2013 Type C |
Specifications as published by Karam. Please confirm the exact model with us before ordering.
A compact single point anchor in anodized aluminium alloy, fixed to walls, ceilings, rooftops or steel structures to give one permanent tie-off point. It weighs about 308 g and Karam lists a minimum breaking strength of 23 kN.
An alloy steel point anchor with a zinc (galvanized) finish for walls, ceilings, rooftops and steel structures, listed for up to 4 users. Two versions: SA10 (380 g, also conforming to ANSI Z359.18:2017 Type A) and the forged SA10A (435 g).
A polished stainless steel anchorage eye for permanent fixing into concrete, set in a pre-drilled hole with an adhesive capsule. Karam lists a minimum breaking strength of 12 kN and a weight of about 300 g.
A stainless steel flange anchor with an electropolished or e-coated finish, bolted to walls, ceilings, rooftops or steel structures. It takes load in the X, Y and Z directions and Karam lists a minimum breaking strength of 23 kN.
A small single point flange anchor in stainless steel, about 60 g, fixed with a standard M12 bolt and nut to walls, ceilings, rooftops or steel structures. Karam lists a minimum breaking strength of 12 kN.
A portable beam clamp whose adjustable jaw fits a wide range of steel beam flange widths, giving a temporary anchor point on site. The SA08 is built in aluminium alloy and brass (1.87 kg); the SA08M (1.56 kg) is listed with a black ED coated finish.
A 25 mm tubular strap with a sewn loop at each end that serves either as a lanyard or as a transportable anchorage point (EN 795 Type B) on a suitable structure. Made in 1 m (LO030100), 1.50 m (LO030150) and 2 m (LO030200).
