Honeywell EVACPRO-MIC Call Station for Evacpro-G2
The call station microphone of the Evacpro-G2 voice alarm system. It links to the controller over RJ45, with two-way RS485 digital communication over distances up to 300 m.
Dealer for HoneywellHoneywell X-618 X-NPMK-B Network Paging Console, Key Operated
A key operated paging console for zone paging and broadcast control on an X-618 system on the same network.
- Key operation for zone paging and broadcast control
- Removable gooseneck microphone
- Built-in loudspeaker for zone monitoring and internal communication
- Digital audio processing, so the transmission path does not affect audio quality
- Expandable with X-K8 or X-K4 key modules
- DC 24 V supply; FCC listed
Standards and approvals: FCC
Specifications
Specifications
| Specification | X-NPMK-B |
|---|---|
| Power Supply Voltage | DC 24V |
| Rated Power | 11W |
| Microphone Frequency Response | 50Hz-15KHz |
| SNR | > 85dB |
| THD | < 0.05% |
| Microphone Input | -44dB±2dB |
| Line Input | 0dBV (1V) |
| Line Output | 0dBV(1V) |
| Monitoring Loudspeaker | 2W/8 Ω |
| Sample Rate | 44.1 KHz, 16Bit |
| Microphone Pole Length | 385 mm |
| Operation Temperature | -10°C～+55°C |
| Storage Temperature | -40°C～+70°C |
| Humidity | <95%, Non-condensation |
| Dimension (W×H×D) | 200 × 46.5 × 200 mm |
| Packing Dimension (W×H×D) | 403 × 133 × 268mm |
| Net weight | 1.7Kg |
| Gross weight | 2.6Kg |
Specifications as published by Honeywell. Please confirm the exact model with us before ordering.
