Supplier for TycoTyco Type EA-1 Protectospray Directional Spray Nozzle, Automatic, Medium Velocity (TFP800)
An automatic directional spray nozzle with a frangible bulb for water spray fixed systems, discharging a filled cone of medium velocity droplets once the bulb operates.
- External deflector type, in three orifice sizes with a wide choice of spray angles and temperature ratings
- Cools exposed vertical, horizontal, curved and irregular surfaces; also used for area coverage and, depending on design density, for fire control or extinguishment
- Bronze body; 1/2 inch NPT thread; maximum working pressure 175 psi
- Re-designation of the Gem Type EA-1
- Tyco lists UL and C-UL Listing and FM Approval
Standards and approvals: UL and C-UL Listed, FM Approved
Specifications
Specifications
| Specification | Details | Details |
|---|---|---|
| Maximum Working Pressure | 175 psi (12,1 bar) (Also see Figure 2, Note 2) | |
| Discharge Coefficient | See Table A | |
| Spray Angles | See Table B | |
| Temperature Rating | See Table C | |
| Finish | and Material See Table D | |
| Thread Connection | 1/2 in. NPT | |
| Frame | Bronze | |
| Bushing (K=1.4 and K=2.8) | Brass | |
| Deflector | Bronze | |
| Pin | Brass | |
| Bulb (11 mm dia.) | Glass | |
| Bulb Seats | Bronze | |
| Spacer | Bronze | |
| Button | Bronze | |
| Spring Plates | Inconel | |
| Gaskets | Copper |
Specifications as published by Tyco. Please confirm the exact model with us before ordering.
