Supplier for KaramKaram Dead Weight Davit on Wheeled Trolley
A free standing davit held steady by a trolley loaded with heavy weight plates, for confined space access and retrieval where no fixed anchorage point is possible.
- Weighted trolley keeps the anchor post stable
- Wheels for moving between work areas
- Upper mast with three height adjustments
- Total weight 750 kg including 650 kg dead weight
- Powder coated aluminium alloy; EN 795:2012 Type E
Standards and approvals: EN 795:2012 Type E, CE
Specifications
Specifications
| Specification | DA07 |
|---|---|
| Material | High strength and durable Aluminium Alloy |
| Finish | Powder Coated |
| System Strength | 21kN |
| Weight | 750kgs ± 0.20kgs including 650kgs dead weight |
| Maximum load capacity | 500 kgs |
Specifications as published by Karam. Please confirm the exact model with us before ordering.
