System Sensor Agile Wireless Sounder Strobe, Red (WSF-RR-RF) or White (WSF-WR-RF) Body
A battery-powered wireless sounder with a red flashing visual alarm device (VAD), approved to EN 54-23 for light coverage category W-3.5-10.
- EN 54-23 visual alarm device, light coverage W-3.5-10, red flash
- 100 dB(A) maximum sound pressure level
- 32 user selectable tones through AgileIQ
- IP21, operating temperature -30 to 55°C
- 4 CR123A 3V batteries, weight 430g with batteries
- EN 54-3, EN 54-23 and EN 54-25
Standards and approvals: EN54-23
Specifications
Specifications
| Specification | Wal L mounted Red or White Sounder Strobe WSF-RR-RF | Wal L mounted Red or White Sounder Strobe WSF-WR-RF |
|---|---|---|
| Ordering Code | WSF-RR-RF | WSF-WR-RF |
| Radio Frequency | 865-870 MHz | 865-870 MHz |
| Transmitting Power | <25mW e.r.p. | <25mW e.r.p. |
| Supply | 4 CR123A 3V Batteries | 4 CR123A 3V Batteries |
| Height | 97mm (with B501RF base) | 97mm (with B501RF base) |
| Length / Diameter | 121mm | 121mm |
| Weight (With batteries) | 430g | 430g |
| Humidity (No condensation) | 10: 93 %RH | 10: 93 %RH |
| Operating Temperature | -30: 55 °C | -30: 55 °C |
| Fire Standard | EN54-25 | EN54-3 | EN54-23 (W-3.5-10) | EN54-25 | EN54-3 | EN54-23 (W-3.5-10) |
| Package weight | 445g | 445g |
| Package size (mm) | 140 L | 155 W | 95 H | 140 L | 155 W | 95 H |
Specifications as published by System Sensor. Please confirm the exact model with us before ordering.
