Dealer for HoneywellA gas detector in the VESDA range that gives early warning of gases for occupant protection and system monitoring, alongside protection against fire. Its built-in Bluetooth pairs with a smart device app for installation, commissioning and maintenance.
Standards and approvals: IEC61010-1, CE, EN 50270, FCC, UL2075
| Specification | Details |
|---|---|
| Supply Voltage | 24 VDC nominal | 11 to 32V DC (Analog 4-20 mA) | 9 to 32V DC (Modbus) | 24V AC 50/60Hz Nominal (20 to 27 VAC) |
| Maximum Power Consumption (24V DC) | 1.2 W (Analog 4-20mA) (toxic), 1.7W (flammable and CO2) | 0.7 W (Modbus) (toxic), 1.2W (flammable and CO2) | Relay Version: additional 0.6W total |
| Maximum Inrush Current (24V DC) | 850 mA |
| Dimensions (WxHxD) | 113 x 113 x 59 mm (4.4 x 4.4 x 2.3 in) |
| Weight | 500 g (1.1 lb) |
| Ingress Protection Rating | IP65, Type 4 (NEMA 250) |
| Casing Material | Polycarbonate (charcoal colour) |
| Operating Conditions | Operating Temperature: −20 to +50 °C (−4 to +122 °F) | Storage Temperature: 0 to +30 °C (+32 to +86 °F) | Humidity: 0 to 99% (non-condensing) | Flammable catalytic versions: 10 to 90% RH. Operating the detector outside this range may result in increased drift and a reduction in detector accuracy. | Atmospheric pressure: 95 to 110 kPa |
| Wire/Terminal size | Pluggable rising clamp style. | 0.5 to 1.5 mm2, 20 to 16 AWG. |
| Output | Analog Output: 0 to 22 mA | Digital Output: Modbus RTU | Relay Output: 2 relays (24 V DC / 240 V | AC, 5 A) |
Specifications as published by Honeywell. Please confirm the exact model with us before ordering.
An aspirating smoke detector that draws air from separate sampling points through microbore tubes, so it can pinpoint the location of a fire threat. It has three sensitivity settings and an IP40 enclosure.
A very early warning aspirating smoke detector for small, business-critical areas of less than 500 m2 (5,380 sq ft). It samples air continuously through a pipe network and detects very small amounts of smoke with light scattering.
An add-on for VESDA-E systems in dusty environments that clears built-up dust and lint out of the sampling pipes. It sends an air pressure wave along the pipe network so that air flows outwards and carries the dust with it.
An integrated power supply for VESDA-E detectors that gives 24 V operating power with battery backup. Its charger supervises and maintains the standby batteries.
An aspirating smoke detector with a built-in SLC module that communicates directly with Notifier panels over the SLC loop, offered in one-pipe and four-pipe models (VEP-A00-1P-NTF-VN, VEP-A00-P-NTF-VN and VEP-A10-P-NTF-VN).
An aspirating smoke detector with sector addressability for up to four sectors and a built-in SLC module for direct connection to Notifier panels (VES-A00-P-NTF-VN and VES-A10-P-NTF-VN).
An addressable reflector-type linear beam smoke detector that works on infra red light obscuration, for large open spaces such as warehouses and atriums. The combined transmitter and receiver connects directly to an analogue loop.
An intelligent reflector-type beam smoke detector that uses IR video imaging, for spacious rooms, open areas and high ceilings, with only one device to install and align.
An addressable reflector-type linear optical beam detector that connects directly to an analogue loop, for buildings with large open spaces.
The 6500 addressable beam detector with a servo-operated test filter, so both the optics and the electronics can be tested remotely.
