Dealer for Balaji Fire SafetyA single outlet hydrant valve in stainless steel (SS 202 or SS 304) with a 63 mm outlet and hand wheel, for wet risers and hydrant systems. Some listings name IS 5290; a few rows under these names show a cast iron body, so we confirm the build before supply.
Standards and approvals: IS - 5290, IS 5290
Sizes: 5 inch to 145 pcd flange
| Size / item | Model | Pressure (service / max / test) |
|---|---|---|
| up to 4 inch | ||
| 5 inch | 44 | |
| 63mm | 163 | |
| 63 MM | 89 | |
| 63 mm | 91 | 10 kg/cm2 |
| 63 MM | 001 | |
| 63 mm(Diameter) | BFS 09 | |
| 145 pcd flange | ||
| SS Single Headed Hydrant Valves | ||
| Single Landing Hydrant Valve Commercial Medium | ||
| Ss Single Headed Fire Hydrant Valve |
| Specification | up to 4 inch | 5 inch | 63mm | 63 MM 89 | 63 mm | 63 MM 001 | 63 mm(Diameter) | 145 pcd flange | Details | Details | Details |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Valve Size | 5 inch | 63mm | 4 inch | up to 4 inch | 3 inch | ||||||
| Grade | SS 202 | 304 | |||||||||
| Automation Grade | Manual | Manual | Manual | Manual | Semi Automatic | Manual | |||||
| Valve Type | Single Head Hydrant Valve | Single Outlet | SINGLE HEAD | Single Outlet | Single Headed | single head | single head | ||||
| Usage/Application | Fire Safety | Fire Safety | Fire Safety | Fire Safety | Commercial | Industrial | Fire Hydrant System | ||||
| Number Of Head | 1 | SINGLE | |||||||||
| Color | Red | Red | Red | red | Red | ||||||
| Weight | 7 Kg | 7 Kg + | |||||||||
| Surface Type | Paint Coted | ||||||||||
| Shape | Round (Base) | ||||||||||
| Hand Wheel Material | Yes | 1 WHEEL | |||||||||
| Item Code | 44 | 163 | 89 | 91 | 001 | ||||||
| Usage | Fire Safety | ||||||||||
| Brand | Balaji Fire Safety | Balaji Fire Safety | BFS | ||||||||
| Material | Stainless Steel | Stainless Steel | Stainless steel | Cast Iron | Stainless Steel | Stainless Steel | |||||
| Packaging Type | Box | Box | |||||||||
| Valve Size. | 63mm | ||||||||||
| Outlet Size | 63 mm | 63 mm | 63 mm | 63 mm | |||||||
| Inlet Size | 80 mm | 63 MM | 63 mn | ||||||||
| Body Material | Cast Iron | Cast Iron | Stainless Steel | ||||||||
| Connection Type | Flanged | Flanged | |||||||||
| Operation | Handwheel | ||||||||||
| Pressure Rating | 10 kg/cm2 | ||||||||||
| Standard | IS 5290 | ||||||||||
| Seat Material | Rubber | ||||||||||
| Coating | Red Paint | ||||||||||
| MAKE | BALAJI | ||||||||||
| Size | 63 MM | 63 mm | 63 mm(Diameter) | 145 pcd flange | 63 mm | ||||||
| Country of Origin | Made in India | ||||||||||
| Water Tightness | 6 KG UP | ||||||||||
| Features | RUST PROOF | ||||||||||
| Number Of Valve | SINGLE HEAD VALVE | ||||||||||
| Number Of Ways | ONE | ||||||||||
| Design Type | FIRE VALVE | ||||||||||
| Type | FIRE VALVE | Fire Hydrants | |||||||||
| Inlet (Type-a) | 3" Nb Flanged For Single Outlet. | ||||||||||
| Outlet | Female Instantaneous. | ||||||||||
| Conforming Specification | IS - 5290 | ||||||||||
| Finishing | Rust Proof | Color Coted | |||||||||
| Pressure | 21 Kgf/cm2 | ||||||||||
| Product Code | BFS 09 | ||||||||||
| PCD | 145 mm | ||||||||||
| Hydrant Type | Single Outlet | ||||||||||
| Structure | Circular | ||||||||||
| Flow Test | 1800 LPM discharge at 7 kgf/cm2 | ||||||||||
| Hydraulic Test | Tested At 21 kgf/cm2 | ||||||||||
| Body & Adapter | Body: 202 & Adapter type: 202 | ||||||||||
| Application | Industrial & Factory |
Specifications as published by Balaji Fire Safety. Please confirm the exact model with us before ordering.
Sizes: 63 mm STANDARD, 63 MM STANDRAD, 63 MM
A single outlet landing valve with a cast iron body and stainless steel working parts, an 80 mm flanged inlet and a 63 mm outlet. Two listings name IS 5290, and one is listed as BIS approved.
Sizes: 4.5 inch
A gunmetal single headed hydrant valve in Balaji's commercial heavy range, which Balaji positions for heavy manufacturing units and industrial sites.
Sizes: 6 inch, 63 MM, 85 MM
A double outlet landing valve with a cast iron body and an 80 mm flanged inlet, feeding two hose lines through 63 mm female instantaneous outlets with lugs. It follows the IS 5290 Type B design, and one listing is ISI marked to IS 5290.
A round 63 mm stainless steel adapter for landing valves, listed by Balaji as a fire hydrant accessory.
Single outlet landing valve for hydrant mains and wet risers, made to IS 5290 Type A with the ISI mark and supplied with an ABS blank cap and chain. The heavy duty K-901 and the standard K901-E come in gunmetal or stainless steel.
Double outlet landing valve that feeds two hose lines from one hydrant point, with a 100 mm inlet. Made to IS 5290 Type B with the ISI mark, tested to 21 kg/cm2, in gunmetal or stainless steel.
Sizes: 80 mm
Bronze fire hydrant (landing) valve made to IS 5290 Type A, 80 mm with flanged ends and one outlet fitted with an instantaneous coupling for the hose.
Sizes: 80 mm
SS 304 stainless steel landing valve designed with reference to IS 5290 Type A, 80 mm with flanged ends and a single instantaneous outlet for the fire hose.
Sizes: 2 ½”
ISI marked gunmetal oblique landing valve made to IS 5290 and generally conforming to BS 5041 Part 1, with a 3 inch flanged inlet and a 2½ inch female instantaneous outlet.
Sizes: 2 ½”
ISI marked gunmetal double headed hydrant valve made to IS 5290, with a 4 inch flanged inlet and 2½ inch female instantaneous outlets.
