Dealer for HoneywellHoneywell Variodyn D1 4XD500 Power Amplifier, 4 x 500 W
A four channel 100 V power amplifier for the Variodyn D1 PAVA system, with its outputs connected to the Variodyn D1 DOM module by the output cable.
- 4 independent channels of 500 W at 100 V
- Class D operating principle
- Connects to the Variodyn D1 DOM by cable
- 230 V AC rated voltage, with power figures also given for 24 V DC operation
- Channel separation above 92 dB; ambient -5 to +55 °C
- EN 54-16 listed
Standards and approvals: EN 54-16
Specifications
Specifications
| Specification | 4XD500 |
|---|---|
| Nominal output power (sin.) | 4 x 500 W |
| Rel. humidity | 40 % to 93 %, (w/o condensation) |
| Dimensions (W x H x D) | 483 x 88 x 454 mm / 2 HU, 19 |
| Net Weight | ca. 14 kg |
| Input impedance | > 20 kΩ, el. symmetrical |
| Housing colour | gray similar RAL 7016 |
| Power consumption (230 V AC) | 15.0 A |
| Power consumption (24 V DC / Voice announcement / 1/3 load) | 40.1 A |
| Power consumption (24 V DC / Voice announcement / 1/8 load) | 17.6 A |
| Channel separation | > 92 dB |
| Power consumption in stand-by mode (230 V AC) | 0.5 A |
| Rated voltage | 230 V AC |
| Rated frequency | 50 to 60 Hz, +10% / -5% |
| Operating principle | Class D |
| Transmission frequency band (-1 dB) | 20 Hz to 20 kHz |
| Distortion factor at max. load / 1kHz | < 0.03 % |
| Ambient temperature during operation | -5 °C to +55 °C |
| Transmission frequency band | 20 Hz to 20 kHz |
| Power amplifier 4 x 500 W / 100 V | 580249 |
| Backup cable RC 44 | 583444 |
| Input cable DOM amplifier (2 x required) | 583491 |
| Output cable 4XV amplifier DOM | 583477.21 |
Specifications as published by Honeywell. Please confirm the exact model with us before ordering.
