Supplier for AaagAaag Foam Water Monitor Nozzle, Gunmetal (AAAG G271)
The gunmetal self educting foam and water nozzle, fixed flow, adjustable from a 90° wide fog to a straight stream.
- Self educting, non aspirated foam or water
- Up to 2000 GPM at 7 bar, sized to the monitor
- Wide fog to straight stream
- Fits 63 to 150 mm monitors; flanged inlet for 150 mm
- Maximum operating pressure 12 bar (175 psi)
Specifications
Specifications
| Specification | Up to 2000 GPM @ 7Bar |
|---|---|
| Model | AAAG G271 |
| Nozzle Body | Gun Metal |
| Maximum Operating Pressure | 12 Bar (175 psi) |
| Flow Rate | Up to 2000 GPM @ 7Bar, According to the size of monitor and flow rate required |
| Inlet | Suitable for 63mm, 75mm, 100mm and 150 mm Monitor sizes |
| Inlet Thread | BSP Thread Female Swivel Flanged Inlet for 150mm Monitor Size |
| Nozzle Spray | Wide Fog: Straight Stream Non Aspirated Foam |
Specifications as published by Aaag. Please confirm the exact model with us before ordering.
