Ravel Sounder Strobe with Selectable Candela (RE-716SS)
A slim sounder strobe for fire, burglar and emergency alarm systems, with four light output settings and two tone settings.
Dealer for RavelRavel Strobe with Selectable Candela (RE-716ST)
A visual alarm strobe with a high power cool white LED and four light output settings, for ceiling or flush wall mounting.
- High power cool white LED, one flash per second
- Four candela settings: 15, 30, 75 and 110 cd
- Ceiling or flush wall mounting on a standard 4 x 4 inch back box
- 24 V DC (16 to 33 V) or FWR
- FR ABS plastic, -10 to 50 °C
- Ravel states UL 1971, ULC-S526 and NFPA 72 (2016 edition) compliance
Standards and approvals: UL 1971, NFPA 72
Specifications
Specifications
| Specification | RE-716ST |
|---|---|
| Material | FR ABS Plastic |
| Pulse Duration | 20ms |
| Input Voltage | 24V DC (16-33V)/FWR |
| Current | 47-73mA @24V |
| Relative Humidity | 93 ± 2 @ 32OC |
| Operating Temperature | -10 to 50OC |
| Candela Intensity | 15cd,30cd,75cd,110cd |
| Flash Rate | 1 flash per second |
| Size | 140(W)*120(H)*51(D)mm |
| Mounting Options | Standard 4’’ * 4”back box |
Specifications as published by Ravel. Please confirm the exact model with us before ordering.
