Supplier for TycoGlass bulb quick response sidewall sprinklers with a 3 mm bulb for light and ordinary hazard buildings, fitted along a wall or beam side just below a smooth ceiling.
Standards and approvals: UL and C-UL Listed, FM Approved, LPCB Approved
| Specification | K=5.6 gpm/psi1/2 (80,6 Lpm/bar1/2) | Horizonta L | Vertica L |
|---|---|---|---|
| Recessed Escutcheon | Signal or Pure White, Jet Black, Grey Aluminum, Chrome Plated, or Brass Plated | ||
| Frame | Bronze | ||
| Button | Brass/Copper | ||
| SIN | TY3331 | TY3431 | |
| SIN entry as printed | Horizontal | Vertical | |
| Orientation | Horizontal | Vertical | |
| K-factor | 5.6 K-factor | 5.6 K-factor | |
| Response | Quick Response | Quick Response | |
| Discharge Coefficient | K=5.6 gpm/psi1/2 (80,6 Lpm/bar1/2) | K=5.6 gpm/psi1/2 (80,6 Lpm/bar1/2) | |
| Maximum Working Pressure | See Table B | See Table B | |
| Temperature Ratings | See Table A | See Table A | |
| Finishes | Sprinkler: See Table C | Sprinkler: See Table C |
Specifications as published by Tyco. Please confirm the exact model with us before ordering.
