Authorised distributor for Sant ValvesSant Valves CR-31 Cast Iron Reflux Valve, Swing Check, IS 5312, PN10
PN10 version of Sant's cast iron swing check type reflux (non return) valve to IS 5312, with bolted cover and IS 1538 flanges. Sizes 50 mm to 300 mm, for water.
- Cast iron body to IS:210 Gr.FG200, straight pattern
- Integral or renewable seat, renewable disc
- Flanges to IS:1538
- Body test 1.5 MPa, seat test 1.0 MPa
Standards and approvals: IS:5312
Sizes: 50 mm to 300 mm
Specifications
Specifications
| Specification | 50 mm | 65 mm | 80 mm | 100 mm | 125 mm | 150 mm | 200 mm | 250 mm | 300 mm |
|---|---|---|---|---|---|---|---|---|---|
| Nominal Size | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 |
| Nominal Size (Inches) | 2 | 2.1/2 | 3 | 4 | 5 | 6 | 8 | 10 | 12 |
| F | 203±2 | 216±2 | 241±2 | 292±3 | 330±3 | 356±3 | 495±3 | 622±4 | 698±4 |
| H (Approx.) | 135 | 150 | 160 | 185 | 225 | 240 | 292 | 340 | 398 |
Specifications as published by Sant Valves. Please confirm the exact model with us before ordering.
