Authorised distributor for Sant ValvesSant Valves DH87X Double Door Check Valve, Grooved
Double door check valve with grooved ends to ISO 6182 in a ductile iron body, for grooved water pipework. PN16, in sizes from 219.1 mm to 377 mm.
- Ductile iron body to EN-GJS-450-10
- Grooved ends to ISO 6182
- Working pressure PN16, temperature range 0°C to 100°C
- Fusion bonded epoxy coating to ANSI/AWWA C550
Sizes: 219.1 mm, 273 mm, 323.9 mm, 377 mm
Specifications
Specifications
| Specification | 219.1 mm | 273 mm | 323.9 mm | 377 mm |
|---|---|---|---|---|
| Inch | 8″ | 10″ | 12″ | 14″ |
| mm | 219.1 | 273 | 323.9 | 377 |
| A | 19.1 | 19.1 | 19.1 | 23.8 |
| B | 11.1 | 12.7 | 12.7 | 12.7 |
| C | 214.4 | 268.28 | 318.29 | 371.1 |
| D | 219 | 273 | 324 | 377 |
| E | 200 | 253 | 307 | 354 |
| F | 165 | 203 | 228 | 258 |
| L | 160 | 180 | 180 | 200 |
Specifications as published by Sant Valves. Please confirm the exact model with us before ordering.
