Dealer for ZolotoZoloto Bronze Globe Valve, Medium Pattern, Screwed (1001)
Medium pattern bronze globe valve for regulating flow, with a rising stem and female threaded ends, 8 mm to 100 mm.
- Female threads to IS 554 / BS 21 / ISO 7
- Screwed in bonnet, inside screw, rising stem, integral seat
- Sheet metal handwheel for a firm grip
- PTFE gland packing
- Maximum working temperature 225°C
Sizes: 8 mm to 100 mm
Specifications
Specifications
| Specification | 8 mm | 10 mm | 15 mm | 20 mm | 25 mm | 32 mm | 40 mm | 50 mm | 65 mm | 80 mm | 100 mm | 1001 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Size (Inches) | 1/4 | 3/8 | 1/2 | 3/4 | 1 | 1 1/4 | 1 1/2 | 2 | 2 1/2 | 3 | 4 | |
| Size (mm) | 8 | 10 | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | |
| A ±1.5 | 33 | 37 | 45 | 53 | 57 | 71 | 80 | 86 | 107 | 123 | 159 | |
| B ~ | 60 | 60 | 70 | 85 | 93 | 109 | 117 | 137 | 154 | 184 | 224 | |
| ØC ~ | 50 | 50 | 60 | 65 | 70 | 80 | 90 | 110 | 120 | 140 | 160 | |
| D | 1/4″ | 3/8″ | 1/2″ | 3/4″ | 1″ | 1 1/4″ | 1 1/2″ | 2″ | 2 1/2″ | 3″ | 4″ | |
| Shell | 20 kg/cm²g (285 psig) | |||||||||||
| Seat | 13.50 kg/cm²g (192 psig) | |||||||||||
| Maximum Working Temperature | 225°C |
Specifications as published by Zoloto. Please confirm the exact model with us before ordering.
