Dealer for ZolotoZoloto Bronze Horizontal Check Valve No.9, SS 410 Trim, Flanged (1014)
Flanged version of the No.9 bronze lift check valve, with SS 410 working parts and flanges to BS 10 Table F, rated for steam at 10.55 kg/cm²g (150 psig). Sizes 15 mm to 100 mm.
- Flanged ends to BS 10 Table F
- Renewable SS 410 (13% Cr) working parts
- Steam working pressure 10.55 kg/cm²g (150 psig)
- Maximum working temperature 225°C
- Mushroom shaped metal disc guided in the bonnet; horizontal lines only
Sizes: 15 mm to 100 mm
Specifications
Specifications
| Specification | 15 mm | 20 mm | 25 mm | 32 mm | 40 mm | 50 mm | 65 mm | 80 mm | 100 mm | 1014 |
|---|---|---|---|---|---|---|---|---|---|---|
| Size (Inches) | 1/2 | 3/4 | 1 | 1 1/4 | 1 1/2 | 2 | 2 1/2 | 3 | 4 | |
| Size (mm) | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | |
| A ±1.5 | 82 | 96 | 112 | 119 | 132 | 157 | 185 | 213 | 248 | |
| B ~ | 48 | 50 | 61 | 72 | 84 | 93 | 109 | 121 | 146 | |
| Shell | 35 kg/cm²g (500 psig) | |||||||||
| Working Pressure (Steam) | 10.55 kg/cm²g (150 psig) | |||||||||
| Maximum Working Temperature | 225°C |
Specifications as published by Zoloto. Please confirm the exact model with us before ordering.
