Supplier for TycoTyco Series TY-FRB Extended Coverage Horizontal Sidewall Sprinklers, K5.6 and K8.0, Light Hazard (TFP296)
3 mm glass bulb extended coverage sidewall sprinklers for hydraulically calculated systems in light hazard buildings such as churches, restaurant seating areas, hotels, schools and offices, covering up to 16 ft wide by 24 ft long.
- K-factor 5.6 or 8.0 gpm/psi½ (80.6 or 115.2 Lpm/bar½)
- QREC rating for many of the listed coverage areas
- Recessed version with a two-piece Style 10 or 40, or Style 20 or 30, escutcheon
- Temperature ratings printed in the data sheet: 57°C, 68°C and 79°C
- Corrosion-resistant coated versions where applicable
- Tyco lists UL and C-UL listing and FM approval
Standards and approvals: UL and C-UL Listed, FM Approved
Specifications
Specifications
| Specification | EC HSW, 5.6K, 1/2 in. NPT | EC HSW, 8.0K, 3/4 in. NPT | Details | Details |
|---|---|---|---|---|
| SIN | TY3332 | TY4332 | ||
| SIN entry as printed | EC HSW, 5.6K, 1/2 in. NPT | EC HSW, 8.0K, 3/4 in. NPT | ||
| Orientation | EC HSW | EC HSW | ||
| K-factor | 5.6K | 8.0K | ||
| Thread | 1/2 in. NPT | 3/4 in. NPT | ||
| Discharge Coefficient | K=5.6 gpm/psi½ (80,6 lpm/bar½) | K=8.0 gpm/psi½ (115,2 lpm/bar½) | ||
| Maximum Working Pressure | See Table B | See Table B | ||
| Temperature Ratings | See Table A | See Table A | ||
| Finishes | Sprinkler: See Table E | Sprinkler: See Table E | ||
| Recessed Escutcheon | White Coated, Chrome Plated, or Brass Plated | |||
| Frame | Bronze | |||
| Button | Brass/Copper |
Specifications as published by Tyco. Please confirm the exact model with us before ordering.
