Apollo Soteria Optical Smoke Detector
An addressable optical smoke detector using Apollo's PureLight sensing technology for false alarm management and reliability, suited to slow burning, smouldering fires.
Authorised distributor for ApolloApollo Soteria Dimension Specialist Optical Smoke Detector (Anti-Ligature)
A flush mounted optical smoke detector with a ruggedised metal face plate held by anti-tamper screws, independently certified to DHF TS001 for anti-ligature use in specialist areas.
- Ruggedised metal face plate with anti-tamper screws
- Certified to DHF TS001 for anti-ligature use
- Integrated switchable isolator, 8-way DIL switch addressing
- CoreProtocol, also listed for Discovery and XP95 systems
- 17 to 35 V dc supply, -20 to 55°C, IP55
- EN 54-7 and EN 54-17, with LPCB, VdS, CPR, BOSEC and Exova approvals
Standards and approvals: EN 54-7, EN 54-17, LPCB, VdS, CPR, BOSEC, Exova
Specifications
Specifications
| Specification | FL6100-600APO |
|---|---|
| Warranty | 10 year |
| Colour | Silver |
| Weight | 321g |
| Materials housing | Polycarbonate |
| Materials terminals | Nickel plated stainless steel |
| Product diameter | 170mm | 6.69in |
| Product depth | 36.45mm | 1.44in |
| Detection principle | Photo-electric light scattering. |
| Analogue value nominal | 23 |
| Analogue value (- tolerance) | 0 |
| Analogue value (+ tolerance) | 4 |
| Analogue value | 23 +4/-0 |
| Alarm level analogue value | 55 |
| Protocol voltage | 5 to 13V peak to peak |
| Protocol voltage (max) | 13V |
| Protocol voltage (min) | 5V |
| Power-up surge current | 1mA |
| Quiescent current | 1000μA |
| Quiescent current tested at | 24V dc |
| Supply voltage (max) | 35V dc |
| Supply voltage (min) | 17V dc |
| Supply voltage (Vmin-Vmax) | 17 to 35V dc |
| Terminal functions L2 | +L2, Loop in & out positive |
| Terminal functions L1 in | -L1 in, Loop (isolated) negative |
| Terminal functions L1 out | Loop out negative |
| Terminal functions +R | +R, Remote indicator positive connection |
| Terminal functions -R | -R, Remote indicator negative connection |
| Polarity | L1 &, L2 are polarity sensitive |
| Sampling frequency | Once per second |
| Humidity (max) | 95%, RH |
| Humidity (min) | 0%, RH |
| Humidity Note | no condensation or icing |
| Humidity | 0% to 95% (no condensation or icing) |
| Operating temperature | -20 to 55°C | -4 to 131°F |
| Operating temperature (max) | 55°C | 131°F |
| Operating temperature (min) | -20°C | -4°F |
| IP rating Value | IP55 |
Specifications as published by Apollo. Please confirm the exact model with us before ordering.
