Authorised distributor for ApolloApollo XP95 Protocol Translator (SIL2)
Installed in the safe area, it keeps communication between the control equipment and intrinsically safe field devices sound, and keeps the system within the limits of its BASEEFA approvals.
- Installed in the safe area
- Links control equipment to I.S. field devices
- Designated SIL2 (Safety Integrity Level 2)
- ESC, LPCB, LR, DNV.GL, CPR and MED approvals
- 19 to 28 V dc supply, -20 to 60°C
- 10 year warranty
Standards and approvals: ESC, LPCB, LR, DNV.GL, CPR, MED
Specifications
Specifications
| Specification | 55000-855APO |
|---|---|
| Warranty | 10 year |
| Colour | Green |
| Weight | 100g |
| Materials housing | Polycarbonate |
| Product length | 110mm | 4.33in |
| Product width | 92.5mm | 3.64in |
| Product depth | 20mm | 0.79in |
| Protocol voltage (min) | 5V |
| Protocol voltage (max) | 9V |
| Protocol voltage | 5 to 9V peak to peak |
| Supply voltage (max) | 28V dc |
| Supply voltage (min) | 19V dc |
| Supply voltage (Vmin-Vmax) | 19 to 28V dc |
| Humidity | 10% to 95% (no condensation or icing) |
| Humidity Note | no condensation or icing |
| Humidity (max) | 95%, RH |
| Humidity (min) | 10%, RH |
| Operating temperature | -20 to 60°C | -4 to 140°F |
| Operating temperature (max) | 60°C | 140°F |
| Operating temperature (min) | -20°C | -4°F |
Specifications as published by Apollo. Please confirm the exact model with us before ordering.
