Dealer for NotifierNotifier ISO-X Fault Isolator Module
An addressable isolator module that protects the fire alarm system against wire-to-wire short circuits on the SLC loops.
- Lets part of the loop keep working when a short circuit occurs
- Resets automatically once the short is corrected
- SEMS screws with clamping plates for easy wiring
- 15 to 32 VDC peak, 0°C to 49°C
- UL and ULC listed, FM approved, with CSFM, MEA, U.S. Coast Guard and Lloyd's Register listings
Standards and approvals: UL: S635 (UOXX); BP6480 (AMCX, APOU), ULC: S635 (OUOXXC, ISO-XA), FM Approved, CSFM: 7165-0028:0214; 7165-0028:0224; 7165- 0028:0243, MEA: 17-96-E; 104-93-E Vol. VI; 290-91-E Vol. V; 317-01- E; 447-99-E, U.S. Coast Guard: 161.002/42/1 (NFS-640); 161.002/50/0, Lloyd’s Register: 11/600013 (NFS2-640/NFS-320/NFS- 320C, excluding B210LP(A)), BSA: 578-81-SA
Specifications
Specifications
| Specification | Details |
|---|---|
| Normal operating voltage | 15 to 32 VDC (peak). |
| Standby current | 450 μA (not isolating) . |
| Maximum current draw | 17 mA (device in isolation, LED latched in alarm). |
| Temperature range | 32°F to 120°F (0°C to 49°C). |
| Relative humidity | 10% to 93% (non-condensing). |
| Weight | 5 oz. (150 grams). |
| Dimensions | 4.5”H x 4.5”W x 0.25” D (11.43 cm H x 11.43 cm W x 0.635 cm D). |
Specifications as published by Notifier. Please confirm the exact model with us before ordering.
