Dealer for Morley by HoneywellMorley by Honeywell HM/D240CMO/UL Addressable Relay Module (Morley UL)
An addressable relay module that gives a dry contact output for fans, door holders, dampers and control equipment, and can reset four-wire smoke detector power.
- Dry contact output activated by panel programming
- For fans, door holders, dampers and other auxiliary devices
- Can reset four-wire smoke detector power
- Relay contacts rated 3.0 A at 30 VDC, resistive, non-coded
- Mounts to a 4 inch square box; 0°C to 49°C
- UL Listed S35595
Standards and approvals: UL Listed: S35595
Download the official Morley by Honeywell catalogue (PDF, 2.3 MB)
Specifications
Specifications
| Specification | HM/D240CMO/UL |
|---|---|
| Normal operating voltage | 15 to 32 VDC |
| Maximum SLC current draw | 6.5 mA (LED on) |
| Average operating current | 230 μA direct poll (CLIP mode) with LED flashing |
| EOL resistance | Not Used. |
| Temperature range | 32°F to 120°F (0°C to 49°C) |
| Humidity range | 10% to 93% non-condensing |
| Dimensions | 4.5" (11.43 cm) high x 4" (10.16 cm) wide x 1.25" (3.175 cm) deep. Mounts to a 4" (10.16 cm) square x 2.215" (5.398 cm) deep box |
| Load Descripton | Resistive |
| Application | Non-Coded |
| Maximum Voltage | 30 VDC |
| Current Rating | 3.0 A |
Specifications as published by Morley by Honeywell. Please confirm the exact model with us before ordering.
