Dealer for Morley by HoneywellMorley by Honeywell MI/D2ICMO Dual Input, Single Output Addressable Module
An addressable module with two monitored input circuits and one volt-free changeover relay, for reading external devices and controlling an external circuit.
- Two monitored inputs: normal, open circuit and alarm
- One single pole volt-free changeover relay
- Relay contacts rated 2A at 30 Vdc, resistive load
- 15 to 30 Vdc, 110g
- -20°C to +60°C, 0 to 95% humidity non-condensing
Download the official Morley by Honeywell catalogue (PDF, 2.3 MB)
Specifications
Specifications
| Specification | MI/D2ICMO |
|---|---|
| Dimensions (H x W x D) | 93 x 94 x 23 (mm) |
| Weight | 110g |
| Operating Temperature | -20 ºC to +60 ºC |
| Relative Humidity | 0 to 95% maximum non-condensing |
| Operating voltage | 15 to 30 Vdc |
| No comms | 340μA at 24 Vdc maximum |
| 1 comms every 5 seconds with LED blink | 660μA at 24 Vdc maximum |
| Relay contacts rating | 2A at 30 Vdc, resistive load. |
| Terminal Wire | 2.5 mm2 maximum |
Specifications as published by Morley by Honeywell. Please confirm the exact model with us before ordering.
