Dealer for Morley by HoneywellMorley by Honeywell MI/D240CMO 240V AC Output Module
A loop-powered wall mounting output module for switching 240Vac loads, with an unsupervised double pole relay that latches on or off on command from the panel.
- For 240V AC loads, wall mounting
- Double pole relay with one normally open and one normally closed contact
- Bistable relay latches in the on or off state
- Output rated 5A at 30 Vdc and 5A at 240 Vac, resistive load
- Loop powered, 15 to 30 Vdc, 200 g
Download the official Morley by Honeywell catalogue (PDF, 2.3 MB)
Specifications
Specifications
| Specification | MI/D240CMO |
|---|---|
| Weight | 200 g |
| Operating Temperature | -20 ºC to +60 ºC |
| Operating voltage | 15 to 30 Vdc |
| No comms | 275μA at 24 Vdc maximum |
| 1 comms every 5 seconds with LED blink | 445μA at 24 Vdc maximum |
| Terminal Wire | 1.5 mm2 maximum |
| Output Rating | 5A at 30 Vdc, resistive load. 5A at 240 Vac, resistive load. |
Specifications as published by Morley by Honeywell. Please confirm the exact model with us before ordering.
