Dealer for Morley by HoneywellMorley by Honeywell MI/DCMO Addressable Control Output Module
A single channel addressable output module that provides either a single alarm circuit or a Form C relay, for door holders, air handling unit shut down and similar functions.
- Single alarm circuit or Form C (changeover) relay output
- Optional supervision of the wiring to the output load
- Rated 2A at 30 Vdc unsupervised, 1.5A at 30 Vdc supervised (resistive load)
- Uses one of the 99 module addresses on a loop
- 15 to 30 Vdc, 110g, -20°C to +60°C
Download the official Morley by Honeywell catalogue (PDF, 2.3 MB)
Specifications
Specifications
| Specification | MI/DCMO |
|---|---|
| Dimensions (H x W x D) | 93 x 94 x 23 (mm) |
| Weight | 110g |
| Operating Temperature | -20 ºC to +60 ºC |
| Operating voltage | 15 to 30 Vdc |
| No comms | 310μA at 24 Vdc maximum |
| 1 comms every 5 seconds with LED blink | 510μA at 24 Vdc maximum |
| Terminal Wire | 2.5 mm2 maximum |
| Unsupervised | 2A at 30 Vdc, resistive load. |
| Supervised | 1.5A at 30 Vdc, resistive load. |
| MI-DCMO | Single channel addressable output module |
Specifications as published by Morley by Honeywell. Please confirm the exact model with us before ordering.
