Dealer for Morley by HoneywellMorley by Honeywell HM/DCMO/UL Addressable Control Module (Morley UL)
An addressable control module that switches 24 VDC audible and visual power and provides a circuit for notification appliances such as horns and strobes, activated by panel programming for a selected zone or area.
- Switches 24 VDC power for horns, strobes and other notification appliances
- Activated through panel programming on a zone or area basis
- 15 to 32 VDC
- Maximum SLC current draw 6.5 mA with LED on
- UL Listed S35595
Standards and approvals: UL Listed: S35595
Download the official Morley by Honeywell catalogue (PDF, 2.3 MB)
Specifications
Specifications
| Specification | HM/DCMO/UL |
|---|---|
| Normal operating voltage | 15 to 32 VDC |
| Maximum SLC current draw | 6.5 mA (LED on) |
| Average operating current | 350 μA direct poll (CLIP mode) with LED flashing |
Specifications as published by Morley by Honeywell. Please confirm the exact model with us before ordering.
