Dealer for Morley by HoneywellMorley by Honeywell HM/DCZRM/UL Zone Monitor Module (Morley UL)
A standard-sized module that monitors one full zone of compatible two-wire, 24 V conventional smoke detectors on a Class B circuit and reports normal, open or alarm status to the panel.
- One zone of two-wire 24 V smoke detectors on a Class B circuit
- Address set on built-in rotary switches
- Supervises the IDC wiring and the connection of external power sources
- 15 to 32 VDC, 3.9K ohm end of line resistor
- Maximum current draw 5.1 mA with LED on
Download the official Morley by Honeywell catalogue (PDF, 2.3 MB)
Specifications
Specifications
| Specification | HM/DCZRM/UL |
|---|---|
| Nominal operating voltage | 15 to 32 VDC |
| Maximum current draw | 5.1 mA (LED on) |
| Maximum IDC wiring resistance | 25 Ohms |
| EOL resistance | 3.9K Ohms |
| Temperature range | 32°F to 120°F (0°C to 49°C) |
Specifications as published by Morley by Honeywell. Please confirm the exact model with us before ordering.
