Dealer for Morley by HoneywellMorley by Honeywell HM/DMMI/UL Addressable Monitor Module (Morley UL)
A standard-sized monitor module that supervises a Class B circuit of dry contact devices such as four-wire smoke detectors, pull stations and water flow devices. It can also power and monitor two-wire smoke detector circuits.
- Supervises a Class B initiating device circuit (IDC)
- For four-wire smoke detectors, manual pull stations, water flow devices and other normally open contacts
- Also monitors and powers two-wire smoke detector circuits
- Reports open, normal or short status; LED flashes on communication and stays on in alarm
- 15 to 32 VDC, 47K ohm end of line resistor
Download the official Morley by Honeywell catalogue (PDF, 2.3 MB)
Specifications
Specifications
| Specification | HM/DMMI/UL |
|---|---|
| Nominal operating voltage | 15 to 32 VDC |
| Maximum SLC current draw | 5.0 mA (LED on) |
| Maximum IDC Voltage | 11 V |
| EOL resistance | 47K Ohms |
Specifications as published by Morley by Honeywell. Please confirm the exact model with us before ordering.
