Dealer for Morley by HoneywellMorley by Honeywell HM/MM3E/UL Mini Monitor Module (Morley UL)
A miniature monitor module that fits in a single-gang box behind the device it monitors and supervises a Class B circuit of dry contact inputs, powered directly from the two-wire SLC loop.
- Miniature size, 1.3 x 2.75 x 0.65 inches
- Mounts in a single-gang box behind the monitored device
- Powered by the two-wire SLC loop, no extra power needed
- High noise (EMF/RFI) immunity, tinned stripped leads
- 47K ohm end of line resistor, 0°C to 49°C
Download the official Morley by Honeywell catalogue (PDF, 2.3 MB)
Specifications
Specifications
| Specification | HM/MM3E/UL |
|---|---|
| Maximum IDC wiring resistance | 1500 Ohms |
| Maximum IDC Voltage | 11 V |
| EOL resistance | 47K Ohms |
| Temperature range | 32°F to 120°F (0°C to 49°C) |
| Humidity range | 10% to 93% non-condensing |
| Wire length | 6” (15.24 cm) minimum |
Specifications as published by Morley by Honeywell. Please confirm the exact model with us before ordering.
